A36 Carbon Steel Bar
Classification :
Keywords :
Carbon Steel Bar
PRODUCT DETAILS
A36 Carbon Steel Bar Description
A36 is a low-carbon steel containing trace amounts of manganese, phosphorus, sulfur, silicon and other elements such as copper. A36 has good weldability and high yield strength, and is the most specified structural steel plate by engineers. ASTM A36 is most commonly manufactured as a variety of structural steel parts. This grade is used for welded, bolted or riveted construction of bridges and buildings, as well as for general structural purposes. Due to its lowest yield point, A36 can be used to design lighter-weight structures and equipment, and provide good weldability.
Product Parameters
Product Name | A36 Carbon Steel Bar | |||
Standard | EN/DIN/JIS/ASTM/BS/ASME/AISI, etc. | |||
Common Round Bar Specifications | 3.0-50.8 mm, Over 50.8-300mm | |||
Flat Steel Common Specifications | 6.35x12.7mm, 6.35x25.4mm, 12.7x25.4mm | |||
Hexagon Bar Common Specifications | AF5.8mm-17mm | |||
Square Bar Common Specifications | AF2mm-14mm, AF6.35mm, 9.5mm, 12.7mm, 15.98mm, 19.0mm, 25.4mm | |||
Length | 1-6meters, Size Accept Custom | |||
Diameter(mm) | Hot Rolling Round Bar | 25-600 | Cold Rolling Square Bar | 6-50.8 |
Hot Rolling Square Bar | 21-54 | Cold Rolling Hexagon Bar | 9.5-65 | |
Cold Rolling Round bar | 6-101.6 | Forged Rebar | 200-1000 | |
Surface Process | Bright, Polished, Black | |||
Other Services | Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc. | |||
Chemical Composition
C | Cu | Fe | Mn | P | Si | S |
0.25～0.290 | 0.20 | 98.0 | 1.03 | 0.040 | 0.280 | 0.050 |
Mechanical Properties
A36 | Limit Tensile Strength | Tensile Strength, Yield Strength | Elongation at Break(Unit: 200mm) | Elongation at Break(Unit: 50mm) | Modulus of Elasticity | Bulk Modulus(Typical for Steel) | Poisson's Ratio | Shear Modulus |
Metric | 400～550MPa | 250MPa | 20.0% | 23.0% | 200GPa | 140GPa | 0.260 | 79.3GPa |
Imperial | 58000～79800psi | 36300psi | 20.0% | 23.0% | 29000ksi | 20300ksi | 0.260 | 11500ksi |
Physical Performance
Physical Performance | Metric | Imperial |
Density | 7.85 g/cm3 | 0.284 lb/in3 |
Scope of Application
Bolted, riveted or welded structures for bridges, buildings and oil drilling rigs.
Used for forming storage tanks, silos, bearing plates, fixtures, rings, templates, fixtures, sprockets, cams, gears, bottom plates, forgings, decoration engineering, piles, brackets, automobiles and agricultural equipment, frames, mechanical parts, etc.
Equivalent Material
National Standard GB | European Standard EN | American Standard ASTM | German Standard DIN,WNr | Japanese Standard JIS | French Standard AFNOR | British Standard BS | Canada HG |
Q235B | S235JR | A283C | St37-2 | SM400A | E24-2 | 40A/40B | 230G |
Italy UNI | India IS | Switzerland SS | Australia ONORM | Norway NS | Spain UNE | International Standards ISO | Portugal NP |
Fe360B | IS2062 | 1311/1312 | RSt360B | NS12123 | AE235B-FN | E235B/Fe360B | FE360-B |
| USA | Japan | Germany | U.K. |
|
France | Italy | Spain | Switzerland | China | |
|
AISI/SAE |
JIS |
W‐nr. |
DIN |
BS |
EN |
AFNOR |
UNI |
UNE |
SS |
GB |
|
A570.36 |
STKM 12A |
1.0038 |
RSt.37‐2 |
4360 |
‐ |
E 24‐2 |
‐ |
‐ |
1311 |
15 |
|
- |
STKM 12C |
- |
- |
40 C |
- |
Ne |
- |
- |
- |
- |
|
1015 |
‐ |
1.0401 |
C15 |
080M15 |
‐ |
CC12 |
C15, C16 |
F.111 |
1350 |
15 |
|
1020 |
‐ |
1.0402 |
C22 |
050A20 |
2C |
CC20 |
C20, C21 |
F.112 |
1450 |
20 |
|
1213 |
SUM22 |
1.0715 |
9SMn28 |
230M07 |
1A |
S250 |
CF9SMn28 |
F.2111 |
1912 |
Y15 |
|
11SMn28 |
||||||||||
|
12L13 |
SUM22L |
1.0718 |
9SMnPb28 |
‐ |
‐ |
S250Pb |
CF9SMnPb28 |
11SMnPb28 |
1914 |
‐ |
|
‐ |
‐ |
1.0722 |
10SPb20 |
‐ |
‐ |
10PbF2 |
CF10Pb20 |
10SPb20 |
‐ |
‐ |
|
1215 |
‐ |
1.0736 |
9SMn36 |
240M07 |
1B |
S300 |
CF9SMn36 |
12SMn35 |
‐ |
Y13 |
|
12L14 |
‐ |
1.0737 |
9SMnPb36 |
‐ |
‐ |
S300PB |
CF9SMnPb36 |
12SMnP35 |
1926 |
‐ |
|
1015 |
S15C |
1.1141 |
Ck15 |
080M15 |
32C |
XC12 |
C16 |
C15K |
1370 |
15 |
|
1025 |
S25C |
1.1158 |
Ck25 |
‐ |
‐ |
‐ |
‐ |
‐ |
‐ |
25 |
|
A572-60 |
‐ |
1.890 |
StE380 |
4360 55 |
‐ |
‐ |
FeE390KG |
‐ |
2145 |
‐ |
|
1035 |
‐ |
1.0501 |
C35 |
060A35 |
‐ |
CC35 |
C35 |
F.113 |
1550 |
35 |
|
1045 |
‐ |
1.0503 |
C45 |
080M46 |
‐ |
CC45 |
C45 |
F.114 |
1650 |
45 |
|
1140 |
‐ |
1.0726 |
35S20 |
212M36 |
8M |
35MF4 |
‐ |
F210G |
1957 |
‐ |
|
1039 |
‐ |
1.1157 |
40Mn4 |
150M36 |
15 |
35M5 |
‐ |
‐ |
‐ |
40Mn |
|
1335 |
SMn438(H) |
1.1167 |
36Mn5 |
‐ |
‐ |
40M5 |
‐ |
36Mn5 |
2120 |
35Mn2 |
|
1330 |
SCMn1 |
1.1170 |
28Mn6 |
150M28 |
14A |
20M5 |
C28Mn |
‐ |
‐ |
30Mn |
|
1035 |
S35C |
1.1183 |
Cf35 |
060A35 |
‐ |
XC38TS |
C36 |
‐ |
1572 |
35Mn |
|
1045 |
S45C |
1.1191 |
Ck45 |
080M46 |
‐ |
XC42 |
C45 |
C45K |
1672 |
Ck45 |
|
1050 |
S50C |
1.1213 |
Cf53 |
060A52 |
‐ |
XC48TS |
C53 |
‐ |
1674 |
50 |
|
1055 |
‐ |
1.0535 |
C55 |
070M55 |
9 |
‐ |
C55 |
‐ |
1655 |
55 |
|
1060 |
‐ |
1.0601 |
C60 |
080A62 |
43D |
CC55 |
C60 |
‐ |
‐ |
60 |
|
1055 |
S55C |
1.1203 |
Ck55 |
070M55 |
‐ |
XC55 |
C50 |
C55K |
‐ |
55 |
|
1060 |
S58C |
1.1221 |
Ck60 |
080A62 |
43D |
XC60 |
C60 |
‐ |
1678 |
60Mn |
|
1095 |
‐ |
1.1274 |
Ck101 |
060A96 |
‐ |
XC100 |
‐ |
F.5117 |
1870 |
‐ |
|
W1 |
SK3 |
1.1545 |
C105W1 |
BW1A |
‐ |
Y105 |
C36KU |
F.5118 |
1880 |
‐ |
|
W210 |
SUP4 |
1.1545 |
C105W1 |
BW2 |
‐ |
Y120 |
C120KU |
F.515 |
2900 |
‐ |
