DIN 17175 Seamless Steel Pipe
Classification :
Keywords :
Carbon Steel Pipe
PRODUCT DETAILS
DIN 17175 Seamless Steel Pipe Description
DIN 17175 is suitable for seamless pipes and is used in the construction of boilers, pipelines, pressure vessels and equipment. The maximum temperature can reach 600 ℃. At the same time, under high pressure, the total stress and related fouling conditions can increase or decrease the temperature limit.
Product Parameters
|
Product Name |
DIN 17175 Seamless Steel Pipe |
|
|
Standard |
EN/DIN/JIS/ASTM/BS/ASME/AISI etc. |
|
|
Outer Diameter |
Seamless: 1/4"-36" |
Welding: 21.3mm-3620mm |
|
Round Tube: 1/2"-10" |
Square Tube/Rectangular Tube: 15x15mm-400x600mm |
|
|
Wall Thickness |
Seamless: 1.25mm-50mm |
Welding: 1.65mm-65mm |
|
Length |
3-12 meters, Support customization |
|
|
Surface Process |
Bright, Polished, Black |
|
|
Other Services |
Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc. |
|
Chemical Composition
|
DIN 17175 |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
Others |
|
St35.8 |
0.17Max |
0.10~0.35 |
0.40~0.80 |
0.040Max |
0.040Max |
- |
- |
- |
- |
|
St45.8 |
0.21Max |
0.10~0.35 |
0.40~1.20 |
0.040Max |
0.040Max |
- |
- |
- |
- |
|
17Mn4 |
0.14~0.20 |
0.20~0.40 |
0.90~1.20 |
0.040Max |
0.040Max |
- |
0.30Max |
- |
- |
|
19Mn5 |
0.17~0.22 |
0.30~0.60 |
1.00~1.30 |
0.040Max |
0.040Max |
- |
0.30Max |
- |
- |
|
15Mo3 |
0.12~0.20 |
0.10~0.35 |
0.40~0.80 |
0.035Max |
0.035Max |
- |
- |
0.25~0.35 |
- |
|
13CrMo910 |
0.10~0.18 |
0.10~0.35 |
0.40~0.70 |
0.035Max |
0.035Max |
- |
0.70~1.10 |
0.45~0.65 |
- |
|
10CrMo910 |
0.08~0.15 |
0.50Max |
0.40~0.70 |
0.035Max |
0.035Max |
- |
2.00~2.50 |
0.90~1.20 |
- |
|
14MoV63 |
0.10~0.18 |
0.10~0.35 |
0.40~0.70 |
0.035Max |
0.035Max |
- |
0.30~0.60 |
0.50~0.70 |
V: 0.22~0.32 |
|
X20CrMoV121 |
0.17~0.23 |
0.50Max |
0.40~0.70 |
0.030Max |
0.030Max |
0.30~0.80 |
10.00~12.50 |
0.80~1.20 |
V: 0.25~0.35 |
Mechanical Properties
|
DIN 17175 |
Material No. |
Minimum Yield Point MPa or N/mm2 |
Tensile Strength |
|
|
WT:16mm Max |
WT:16-40mm |
|||
|
St35.8 |
1.0305 |
235 |
225 |
360~480 |
|
St45.8 |
1.0405 |
- |
245 |
410~530 |
|
17Mn4 |
1.0481 |
- |
275 |
460~580 |
|
19Mn5 |
1.0482 |
- |
315 |
510~610 |
|
15Mo3 |
1.5415 |
275 |
275 |
450~600 |
|
13CrMo910 |
1.7335 |
295 |
295 |
440~590 |
|
10CrMo910 |
1.7380 |
285 |
285 |
450~600 |
|
14MoV63 |
1.7715 |
325 |
325 |
460~610 |
|
X20CrMoV121 |
1.4922 |
490 |
490 |
690~850 |
Scope of Application
DIN 17175 alloy steel pipe adopts heat-resistant pipe, which is suitable for high-pressure environment below 600 ℃. The application scope includes the construction of boilers, pipelines, pressure vessels and equipment.
| USA | Japan | Germany | U.K. |
|
France | Italy | Spain | Switzerland | China | |
|
AISI/SAE |
JIS |
W‐nr. |
DIN |
BS |
EN |
AFNOR |
UNI |
UNE |
SS |
GB |
|
A570.36 |
STKM 12A |
1.0038 |
RSt.37‐2 |
4360 |
‐ |
E 24‐2 |
‐ |
‐ |
1311 |
15 |
|
- |
STKM 12C |
- |
- |
40 C |
- |
Ne |
- |
- |
- |
- |
|
1015 |
‐ |
1.0401 |
C15 |
080M15 |
‐ |
CC12 |
C15, C16 |
F.111 |
1350 |
15 |
|
1020 |
‐ |
1.0402 |
C22 |
050A20 |
2C |
CC20 |
C20, C21 |
F.112 |
1450 |
20 |
|
1213 |
SUM22 |
1.0715 |
9SMn28 |
230M07 |
1A |
S250 |
CF9SMn28 |
F.2111 |
1912 |
Y15 |
|
11SMn28 |
||||||||||
|
12L13 |
SUM22L |
1.0718 |
9SMnPb28 |
‐ |
‐ |
S250Pb |
CF9SMnPb28 |
11SMnPb28 |
1914 |
‐ |
|
‐ |
‐ |
1.0722 |
10SPb20 |
‐ |
‐ |
10PbF2 |
CF10Pb20 |
10SPb20 |
‐ |
‐ |
|
1215 |
‐ |
1.0736 |
9SMn36 |
240M07 |
1B |
S300 |
CF9SMn36 |
12SMn35 |
‐ |
Y13 |
|
12L14 |
‐ |
1.0737 |
9SMnPb36 |
‐ |
‐ |
S300PB |
CF9SMnPb36 |
12SMnP35 |
1926 |
‐ |
|
1015 |
S15C |
1.1141 |
Ck15 |
080M15 |
32C |
XC12 |
C16 |
C15K |
1370 |
15 |
|
1025 |
S25C |
1.1158 |
Ck25 |
‐ |
‐ |
‐ |
‐ |
‐ |
‐ |
25 |
|
A572-60 |
‐ |
1.890 |
StE380 |
4360 55 |
‐ |
‐ |
FeE390KG |
‐ |
2145 |
‐ |
|
1035 |
‐ |
1.0501 |
C35 |
060A35 |
‐ |
CC35 |
C35 |
F.113 |
1550 |
35 |
|
1045 |
‐ |
1.0503 |
C45 |
080M46 |
‐ |
CC45 |
C45 |
F.114 |
1650 |
45 |
|
1140 |
‐ |
1.0726 |
35S20 |
212M36 |
8M |
35MF4 |
‐ |
F210G |
1957 |
‐ |
|
1039 |
‐ |
1.1157 |
40Mn4 |
150M36 |
15 |
35M5 |
‐ |
‐ |
‐ |
40Mn |
|
1335 |
SMn438(H) |
1.1167 |
36Mn5 |
‐ |
‐ |
40M5 |
‐ |
36Mn5 |
2120 |
35Mn2 |
|
1330 |
SCMn1 |
1.1170 |
28Mn6 |
150M28 |
14A |
20M5 |
C28Mn |
‐ |
‐ |
30Mn |
|
1035 |
S35C |
1.1183 |
Cf35 |
060A35 |
‐ |
XC38TS |
C36 |
‐ |
1572 |
35Mn |
|
1045 |
S45C |
1.1191 |
Ck45 |
080M46 |
‐ |
XC42 |
C45 |
C45K |
1672 |
Ck45 |
|
1050 |
S50C |
1.1213 |
Cf53 |
060A52 |
‐ |
XC48TS |
C53 |
‐ |
1674 |
50 |
|
1055 |
‐ |
1.0535 |
C55 |
070M55 |
9 |
‐ |
C55 |
‐ |
1655 |
55 |
|
1060 |
‐ |
1.0601 |
C60 |
080A62 |
43D |
CC55 |
C60 |
‐ |
‐ |
60 |
|
1055 |
S55C |
1.1203 |
Ck55 |
070M55 |
‐ |
XC55 |
C50 |
C55K |
‐ |
55 |
|
1060 |
S58C |
1.1221 |
Ck60 |
080A62 |
43D |
XC60 |
C60 |
‐ |
1678 |
60Mn |
|
1095 |
‐ |
1.1274 |
Ck101 |
060A96 |
‐ |
XC100 |
‐ |
F.5117 |
1870 |
‐ |
|
W1 |
SK3 |
1.1545 |
C105W1 |
BW1A |
‐ |
Y105 |
C36KU |
F.5118 |
1880 |
‐ |
|
W210 |
SUP4 |
1.1545 |
C105W1 |
BW2 |
‐ |
Y120 |
C120KU |
F.515 |
2900 |
‐ |
Packing and delivery
We can providewooden pallet packaging,Wooden packing,Steel strapping packaging,Plastic packaging and other packaging methods.We are willing to package and ship products according to the weight, specifications, materials, economic costs and customer requirements.We can provide container or bulk transportation, road, rail or inland waterway and other land transportation methods for export. Of course, if there are special requirements, we can also use air transportation.
